Description:

The Cub Cadet® CC30 30-inch Compact Riding Lawn Mower has a powerful 10.5 HP engine. It is made to fit in tight spaces and can be easily stored. You can change your mowing speed with its 6-speed, Shift-on-the-Go™ transmission. To keep your lawn healthy, use the included mulch plug. This will return nutrients to the soil and help prevent thatch buildup.

Features:

• A 10.5 HP*/344cc Briggs & Stratton® engine is designed to deliver reliable power to tackle your yard
• 30" side-discharge steel cutting deck is designed to fit through gates 36" wide or larger
• 6-speed Shift On The Go™ transmission has a dash panel control that is easy to see and adjust
• Space-saving design makes the CC30 riding mower easy to store in garages and sheds

Specifications:

Engine

• Engine Brand: Briggs & Stratton®
• Engine Model Number: 21R707-0152
• Engine Displacement: 344cc
• Engine Output: N/A
• Starter Type: Electric
• Fuel Tank Capacity: 1.3 gal. US (4.92 L)
• Cylinders: Single
• Engine Start: Ignition Key
• Engine Oil Capacity: 1.5 qts. US (1.42 L)
• Lubrication: Fully pressurized
• Charging System: 12 amp regulated
• Fuel Gauge: No
• Governor: Mechanical
• Choke: Choke-a-matic
• Oil Filter: No
• Fuel Delivery: Carburetor

Battery

• Battery: 210 CCA
• Battery Type: AGM (Absorbent Glass Mat)
• Battery Voltage: 12V

Drive System

• Transmission: 6-Speed
• Forward Speed: 4 MPH / 6.4 Km/h
• Reverse Speed: 2 MPH / 3.2 Km/h
• Rear Axle: 3/4"
• Drive System: CVT
• Transmission Housing: Cast aluminum
• Rear Differential Lock: No

Cutting Deck

• Deck Cutting Width: 30 in
• Deck Wash: Yes
• Deck Material: 14-gauge steel
• Deck Engagement (PTO): Manual
• Deck Construction: Stamped
• Blade(s): 1
• Deck Lift: Manual
• Cutting Height Range: 1.5" - 4"
• Anti-Scalping: N/A
• Deck Positions: 5

Chassis

• Frame: Robotically welded
• Front Axle: Steel
• Turning Radius: 18"
• Bumper: Steel Tube
• Rear Tow Hitch: Yes
• Corrosion Protection: Yes
• Front Pivot Bar: Steel

Controls

• Cruise Control: No
• Brakes: Disc

Comfort

• Seat Type: Mid-back
• Armrests: No
• Seat Adjustment: Knob
• Floor Mats: Integral

Wheels

• Bearing Type: Poly Bushing
• Rear Tires: 16" x 6.5" - 8”
• Front Tires: 13" x 5" - 6”
• Tire Tread: Turf Saver

Specifications

• Series: CC30 Series

Additional Specifications

• Mulch Kit: Included
• Headlight(s): No
• Cup Holder: Yes
• Operator Presence System: Yes

Model Number

• Model Number: 13AC26JD596

Warranty

• Residential Warranty: 3-year limited
• Commercial Warranty: No
